On Grid Solar System

An on-grid solar system, also known as a grid-tied or grid-connected solar system, works by generating electricity from solar panels and feeding that electricity directly into the utility grid. Here's a concise breakdown of how it works:

  • 1. Solar panels: Photovoltaic (PV) panels, typically installed on rooftops or in open areas, convert sunlight into DC (direct current) electricity.

  • 2. Inverter: The DC electricity produced by the solar panels is sent to an inverter, which converts it into AC (alternating current) electricity, suitable for use in homes and businesses.

  • 3. Power meter: The AC electricity from the inverter is sent to the main electrical service panel and distributed throughout the building for immediate use. Any excess electricity not consumed is sent back to the grid.

  • 4. Grid connection: The solar system remains connected to the utility grid, allowing the flow of electricity in both directions. During periods of low solar production (e.g., nighttime), electricity is drawn from the grid as needed.

  • 5. Net metering: When the solar system generates more electricity than the building consumes, the excess power is sent back to the grid. A bi-directional meter tracks the electricity flowing in both directions, and the owner receives credit for the excess energy supplied to the grid.

  • 6. Utility interaction: The utility company credits the owner for the excess electricity generated, usually through a net metering or feed-in tariff program. These credits can offset the electricity consumed from the grid during times of low solar production.

    • Overall, an on-grid solar system allows users to generate their electricity, reduce reliance on the grid, and potentially earn credits for surplus energy while maintaining a stable connection to the utility company.

Off Grid Solar System

An off-grid solar system, also known as a standalone or independent solar system, works by generating and storing electricity from solar panels to meet the energy needs of a building or facility without relying on the utility grid. Here's a concise breakdown of how it works:

  • 1. Solar panels: Photovoltaic (PV) panels, typically installed on rooftops or in open areas, convert sunlight into DC (direct current) electricity.

  • 2. Charge controller: The DC electricity generated by the solar panels is sent to a charge controller, which regulates the charging of the battery bank and prevents overcharging.

  • 3. Battery bank: The electricity from the charge controller is stored in a battery bank, typically consisting of multiple deep-cycle batteries. The batteries store the excess energy generated during the day for use during periods of low solar production or at night.

  • 4. Inverter: When AC (alternating current) electricity is needed, such as to power household appliances, the DC electricity from the batteries is sent to an inverter. The inverter converts the stored DC electricity into AC electricity, making it suitable for use in homes or businesses.

  • 5. Power distribution: The AC electricity from the inverter is distributed throughout the building to power lights, appliances, and other electrical loads.

  • 6. Backup generator (optional): In some off-grid systems, a backup generator may be included to provide additional power during prolonged periods of low solar production or when the battery capacity is depleted. The generator is typically fueled by diesel, propane, or other sources.

    • By combining solar panels, batteries, charge controllers, inverters, and potentially a backup generator, an off-grid solar system enables self-sufficiency in generating and storing electricity. It allows users to power their electrical needs independently, even in remote locations or areas without access to the utility grid.

Hybrid Solar System

A hybrid solar system combines the features of both on-grid and off-grid systems, allowing users to utilize solar power while still having a connection to the utility grid. Here's a concise breakdown of how a hybrid solar system works:

  • 1. Solar panels: Photovoltaic (PV) panels convert sunlight into DC (direct current) electricity.

  • 2. Inverter: The DC electricity generated by the solar panels is sent to an inverter, which converts it into AC (alternating current) electricity suitable for use in homes and businesses.

  • 3. Power distribution: The AC electricity from the inverter is distributed throughout the building to power electrical loads.

    • Now, depending on the electricity demand and availability, a hybrid solar system can operate in different modes:
    • a) Grid-tied mode: When solar production exceeds the building's electricity demand, the excess power is fed back into the grid, similar to an on-grid system. The owner may receive credits or compensation for the excess energy supplied to the grid through net metering or feed-in tariff programs.
    • b) Off-grid mode: During power outages or when the grid is unavailable, the hybrid solar system can function as an off-grid system. The inverter diverts excess solar power to charge the battery bank, storing it for later use.
    • c) Battery backup mode: When solar production is insufficient or during peak demand periods, the hybrid system can draw power from the battery bank to supplement the solar generation. This mode reduces the reliance on the grid, allowing the stored energy to be utilized instead of purchasing electricity from the utility.

      • Grid connection and synchronization: In hybrid systems, the solar system remains connected to the utility grid, enabling the flow of electricity in both directions. An additional feature is a synchronization mechanism that ensures a smooth transition between grid-connected and off-grid modes.
      The hybrid solar system optimizes energy usage by utilizing solar power, storing excess energy in batteries, and interacting with the grid as needed. It offers the benefits of reduced electricity bills, backup power during outages, and the flexibility to operate independently or with grid support.
